Model
|
1000VA
|
1500VA
|
2000VA
|
3000VA
|
5000VA
|
||||
|
Input Voltage(DC)
|
12V/24V
|
12V/24V
|
12V/24V
|
24V/48V
|
24V/48V
|
||||
|
Nominal Voltage
|
220VAC(Standard)
|
|
|
|
|
||||
|
Voltage Range
|
154-264VAC ±3(Normal Mode);185-264VAC±3V(UPS Model);175-285VAC±3V(AVR Model);
|
|
|
|
|
||||
|
Frequency
|
50/60Hz±5%
|
|
|
|
|
||||
|
Power Factor
|
0.8
|
|
|
|
|
||||
|
Rated Power
|
800W
|
1200W
|
1600W
|
2400W
|
4000W
|
||||
|
Output Voltage(AC)
|
The output voltage under AC is the same as the input voltage
220VAC±10%(With AVR function) |
|
|
|
|
||||
|
Output Frequency (AC)
|
The output voltage frequency under AC is the same as the input frequency
|
|
|
|
|
||||
|
Output Voltage(DC)
|
220VAC±3%
|
|
|
|
|
||||
|
Output Frequency (DC)
|
50/60Hz±1%
|
|
|
|
|
||||
|
Waveform
|
Pure Sine Wave
|
|
|
|
|
||||
|
Battery Type
|
External lead acid battery or water battery
|
|
|
|
|
||||
|
Battery voltage
|
12/24VDC
|
12/24VDC
|
12/24VDC
|
24/48VDC
|
24/48VDC
|
||||
|
Battery Charging Voltage
|
13.75/27VDC
|
13.75/27VDC
|
13.75/27VDC
|
27/54VDC
|
27/54VDC
|
||||
|
Maximum pv array power
|
12V:800W / 24V:1600W/ 48V:3200W
|
|
|
|
|
||||
|
PV Input Voltage Range (PWM Controller)
|
12V:MPPT 15V-150VDC / PWM 15V-30VDC
24V:MPPT 30V-150VDC / PWM 30V-60VDC 48V:MPPT 60V-150VDC / PWM 60V-105VDC |
|
|
|
|
||||
|
Maximum photovoltaic display open circuit voltage
|
12V:MPPT 150VDC / PWM 30VDC
24V:MPPT 150VDC / PWM 60VDC 48V:MPPT 150VDC / PWM 105VDC |
|
|
|
|
||||
|
Maximum solar charging current
|
60A
|
|
|
|
|
||||
|
Maximum AC charging current
|
15A/8A
|
30A/15A
|
40A/20A
|
30A/15A
|
42A/21A
|
||||
|
Battery charging voltage range
|
154-280VAC
|
|
|
|
|
||||
|
Transfer Time
|
≤10ms(UPS mode)/≤20ms (INV mode)
|
|
|
|
|
||||
|
Load peak ratio
|
(MAX)3:1
|
|
|
|
|
||||
|
Static power(W)
|
5W
|
11.5W
|
13W
|
15W
|
20W
|
||||
